醫療與生技過濾應用
Filtration for Medical & Biotech Applications
蛋白過濾、細胞分離與培養等應用，對膜材與孔徑各有不同需求。我們提供 PES、Nylon、PVDF 與 PP 中空纖維膜，從材料規格、孔徑分析到封裝尺寸，與研發團隊討論適合專案的選擇，銜接後續測試與開發。Protein filtration, cell separation and cell culture each call for different membrane materials and pore sizes. Our PES, Nylon, PVDF and PP hollow-fiber membranes provide options for development teams to discuss, from material specifications and pore-size analysis to packaging dimensions, as they plan further testing and development.
情境示意圖（AI 生成），非實際產品／廠房照片或檢驗證據。Illustrative image (AI-generated), not a real product/facility photo or test evidence.
定位 Positioning
膜淨材料生產微過濾中空絲膜，以相轉換 NTV-IPS 工藝鑄造不對稱孔隙結構，材質涵蓋 PES、Nylon、PVDF 與 PP，並持續研究膜材孔徑調整。特定醫療生技用途仍須依材料規格、測試資料及適用要求逐項評估。
mbranfiltra makes microfiltration hollow-fiber membranes using the NTV-IPS phase-inversion process, which casts an asymmetric pore structure, in PES, Nylon, PVDF and PP, and continues research on adjusting membrane pore size. Specific medical and biotech uses require assessment against material specifications, test data and applicable requirements.
應用領域 Applications
蛋白過濾Protein filtration
細胞濃縮、分離、培養Cell concentration, separation and culture
血液透析Hemodialysis
疫苗過濾Vaccine filtration
外泌體Exosomes
製藥／生技製程液體過濾Pharmaceutical and biotech process liquid filtration
以上為應用方向，不代表已有案例或驗證結果。各應用的適用性需依實際製程、法規與驗證結果確認，並非醫療器材或滅菌等級宣稱。
These are application areas, not case studies or validated results. Suitability for each use depends on your process, regulations and validation; this is not a medical-device or sterility claim.
點選圖片可開啟原圖放大 Click an image to open it full size
- 膜孔結構 Membrane pore structure 系統型錄 p2 System brochure p2 ↗
- 外泌體回收與標記分析（型錄實驗，60 nm） EV recovery and marker analysis (brochure experiment, 60 nm) 系統型錄 p2 System brochure p2 ↗
- 明基透析 TFF 自動化系統（明基透析設備） BenQ Dialysis automated TFF system (BenQ Dialysis equipment) 系統型錄 p5 System brochure p5 ↗
明基透析 Qflow 中空纖維過濾器（膜淨 mPES 膜） BenQ Qflow hollow fiber filter with mbranfiltra mPES membrane
專為切向流過濾（TFF）設計，用於純化、濃縮與透濾；明基透析型錄另列外泌體（EV）等研究用濃縮與分離數據。
Designed for tangential flow filtration (TFF): purification, concentration and diafiltration. BenQ Dialysis's brochure also shows research-use concentration and separation of extracellular vesicles (EVs / exosomes).
- 客製系列 S100／S180／S350：孔徑 60 或 100 nm，膜面積 100／180／350 cm²（系統型錄 p2）Customized series S100 / S180 / S350: pore size 60 or 100 nm, filtering surface 100 / 180 / 350 cm² (system brochure p2)
- 流量 @10000/s：200／358／716 ml/min；最大操作壓力 30 psi（60 nm）／26 psi（100 nm）Flow rate @10000/s: 200 / 358 / 716 ml/min; maximum operating pressure 30 psi (60 nm) / 26 psi (100 nm)
- 標準系列：Lab、Pilot、Process 三種規模，MWCO／孔徑 10 kDa–0.65 μm（系統型錄 p3–p4）Standard series: lab, pilot and process sizes, MWCO / pore size 10 kDa – 0.65 μm (system brochure p3–p4)
Qflow-Neo 為明基透析的 TFF 自動化分離系統（設備，系統型錄 p5），與濾器分開列示。
Qflow-Neo is BenQ Dialysis's automated TFF separation system (equipment, system brochure p5); it is listed separately from the filters.
規格、標準與用途依明基透析型錄所載；型錄註明規格可能變更，恕不另行通知。
Specifications, standards and uses are as printed in BenQ Dialysis's brochures, which state that specifications may change without notice.
Mbranguard 中空纖維膜濾心（MGN 系列） Mbranguard hollow fiber membrane cartridge (MGN series)
Mbranguard MGN 也用於生技製藥製程的液體過濾。PES 中空纖維膜濾心，絕對過濾等級 60／100／200 nm，型錄列出的應用產業包含製藥；原料逐批對應 FDA 21 CFR 211.72 與 210.3(b)(6)，並有第三方不脫落纖維檢測。是否作為除菌級過濾使用，須依客戶製程進行細菌截留確效。
Mbranguard MGN is also used for liquid filtration in biotech and pharmaceutical processes. It is a PES hollow-fiber membrane cartridge with absolute removal ratings of 60 / 100 / 200 nm, and the datasheet lists pharmaceuticals among its industries. Raw materials are documented batch by batch against FDA 21 CFR 211.72 and 210.3(b)(6), and a third-party test found no released fibers. Use as a sterilizing-grade filter requires bacterial-retention validation in the customer's own process.
- 材質：PES 膜、PP 殼體、PUR 封膠；O-ring 可選 EPDM／Viton／Silicon／TeflonMaterials: PES membrane, PP housing, PUR potting; O-ring EPDM / Viton / Silicon / Teflon
- 絕對過濾等級 60／100／200 nm；過濾面積 1.8 m²；操作溫度 4–40 °C；外徑 68 mmAbsolute removal rating 60 / 100 / 200 nm; filtration area 1.8 m²; operating temperature 4–40 °C; outer diameter 68 mm
- 長度 5／10／20／30／40 吋；端蓋：雙開口、222/Flat、222/Fin、226/Flat、226/FinLengths 5" / 10" / 20" / 30" / 40"; end caps: double open end, 222/Flat, 222/Fin, 226/Flat, 226/Fin
- 每批原料檢驗資料由原料供應商逐批提供，對應 FDA 21 CFR 條目：PP 177.1520、PES 177.2440、PUR 177.1680、濾材 211.72、不脫落纖維濾材 210.3(b)(6)。Raw-material test data for each batch are provided by the raw-material suppliers, against FDA 21 CFR items: PP 177.1520, PES 177.2440, PUR 177.1680, filters 211.72, non-fiber-releasing filter 210.3(b)(6).
- 第三方清潔度檢測：明基透析科技生物實驗室報告 BDT-NT-250802（2025-08-11 發行），依 21 CFR 210.3(b)(6) Nonfiber Releasing Filter——「鏡檢後，沒有發現雜質纖維」；僅適用該受測樣品，報告僅引用、不轉載。Third-party cleanliness test: BenQ Dialysis Technology Corp. biology lab report BDT-NT-250802 (issued 2025-08-11), per 21 CFR 210.3(b)(6) Nonfiber Releasing Filter -- "no impurity fibers found under microscopy". Applies to the tested sample only; the report is cited, not reproduced.
技術概要 Technical Overview
| 項目Item | 內容Detail |
|---|---|
| 薄膜材質Materials | PES、Nylon（親水性高分子）；PVDF、PP（疏水性高分子）PES and Nylon (hydrophilic polymers); PVDF and PP (hydrophobic polymers) |
| 膜型式Format | 自我支撐的微過濾中空絲膜（HF-MF）Self-supporting microfiltration hollow-fiber membrane (HF-MF) |
| 孔隙結構Structure | NTV-IPS 相轉換工藝形成不對稱孔隙結構Asymmetric pore structure formed by NTV-IPS phase inversion |
| 孔徑Pore size | 透過技術調整，符合各種不同的用途Adjustable through the technology to suit different uses |
| 實驗與分析Laboratory and analysis | 通孔孔徑分析儀（CFP）、水質分析儀，以及客戶材料與水樣分析服務Capillary flow porometer (CFP) and water-quality analyzer; analysis of customer materials and water samples |
需要孔徑分布、蛋白吸附或流量等數據？ Need pore-size distribution, protein-binding or flow data for your process?
告訴我們應用、膜材與操作條件，我們會依適合的型號回覆可提供的規格與檢驗報告。
Tell us your application, membrane material and operating conditions. We will reply with the specifications and test reports we can provide for a suitable model.
第三方檢驗結果 Third-party Test Results
| 檢驗項目Test | 結果Result |
|---|---|
| SGS 檢驗報告 SGS test report | 依 SGS 報告 PX/2020/A011301（受測樣品 MF02-M1，2020-10-23）：大腸桿菌除菌率大於 99.9%。僅適用該受測樣品，非全產品線保證。 Per SGS report PX/2020/A011301 (sample MF02-M1, 2020-10-23): E. coli removal rate above 99.9%. Applies to this sample only, not the whole product line. |
| ISO 10993-5 標準 ISO 10993-5 | 細胞毒性測試，依報告 M62-200500018001（ISO 10993-5，2020-05）：2 級／輕微，存活率降 22.2%——於本試驗條件下不具細胞毒性。僅適用該受測樣品。 Cytotoxicity test, per report M62-200500018001 (ISO 10993-5, 2020-05): grade 2/mild, 22.2% viability reduction — not cytotoxic under the test conditions. Applies to this sample only. |
| BENQ 測試報告 BENQ test report | 依明基透析科技報告 BDT-NT-231207（受測樣品 MF002，2023-12-20）：大腸桿菌清除率大於 99.9%。僅適用該受測樣品，非全產品線保證。 Per BenQ Dialysis Technology report BDT-NT-231207 (sample MF002, 2023-12-20): E. coli clearance rate above 99.9%. Applies to this sample only, not the whole product line. |
| 台美檢驗 Taiwan–US inspection | 依台美檢驗科技（SUPERLAB）報告 M61-200200105（製造日期 2019/12，2020-02-13；同一份 5 頁報告的第 1、2 頁）：塑化劑與重金屬均未檢出。僅適用該受測樣品，非全產品線保證。 Per Taiwan–US Testing Technology (SUPERLAB) report M61-200200105 (mfd. 2019/12, 2020-02-13; pages 1–2 of the same 5-page report): no residual plasticizers or heavy metals detected. Applies to this sample only, not the whole product line. |
報告編號、受測樣品、日期與方法見下方報告掃描檔。各結果僅適用其受測樣品與日期，並非全產品線的共同保證；下方台美檢驗兩項結果為同一份 5 頁報告的第 1、2 頁，並非兩份獨立報告。
Report number, tested sample, date and method are shown with each report scan below. Each result applies only to the specific sample and date tested, not a blanket guarantee across the whole product line; the two Taiwan–US results below are two pages of the same 5-page report, not two separate tests.
各項結果對應各自的測試樣品與條件，並非同一型號的綜合規格。
Each result applies to its own tested sample and conditions; they are not one combined specification.
BenQ Dialysis Technology Test Report No. BDT-NT-260504 (LRV 8 challenge test) — tested sample: Mbranfiltra water fiber, lot 20260512, report date 2026-05-22. Test solution prepared by the testing lab, 550 mL of pure water. Escherichia coli BCRC11634: 4×10⁸ → 1 CFU; Pseudomonas paraeruginosa BCRC11633: 3×10⁹ → 5 CFU (removal rate >99.999999% for both; log reduction value LRV ≈ 8.6 and 8.8, calculated from the report figures as log₁₀ of before ÷ after).
中文報告 PDF Chinese report (PDF) ・ 英文報告 PDF English report (PDF)
BenQ Dialysis Technology Test Report No. BDT-NT-260504-1 — tested sample: Mbranfiltra water fiber, lot 20260512, report date 2026-05-22. 550 mL of pure water; Escherichia coli BCRC11634 reduced from 4×10⁸ to 1 CFU (removal rate >99.999999%; LRV ≈ 8.6, calculated from the report figures).
中文報告 PDF Chinese report (PDF) ・ 英文報告 PDF English report (PDF)
BenQ Dialysis Technology Test Report No. BDT-NT-260504-2 — tested sample: Mbranfiltra water fiber, lot 20260512, report date 2026-05-22. 550 mL of pure water; Pseudomonas paraeruginosa BCRC11633 reduced from 3×10⁹ to 5 CFU (removal rate >99.999999%; LRV ≈ 8.8, calculated from the report figures).
中文報告 PDF Chinese report (PDF) ・ 英文報告 PDF English report (PDF)
BenQ Dialysis Technology Test Report No. BDT-NT-260101-2 — tested sample: Mbranfiltra water fiber, lot 20260115, report date 2026-02-06. 550 mL of pure water; Enterococcus faecalis BCRC10066 reduced from 4.0×10⁸ to 4 CFU (removal rate >99.99999%; LRV ≈ 8.0, calculated from the report figures).
中文報告 PDF Chinese report (PDF) ・ 英文報告 PDF English report (PDF)
BenQ Dialysis Technology Test Report No. BDT-NT-260101-1 — tested sample: Mbranfiltra water fiber, lot 20260115, report date 2026-02-06. 550 mL of pure water; Salmonella Typhimurium BCRC10747 reduced from 6.0×10⁸ to 30 CFU (removal rate >99.9999%; LRV ≈ 7.3, calculated from the report figures).
中文報告 PDF Chinese report (PDF) ・ 英文報告 PDF English report (PDF)
SGS Test Report No. PX/2020/A011301 — sample MF02-M1, tested 2020-10-23. Water filtered at 1.6 L/min for 5 min; E. coli reduced from 5.7×10³ to <1 CFU/100mL (removal rate >99.9%).
Cytotoxicity Test Report No. M62-200500018001 (per ISO 10993-5:2009) — sample: hollow-fiber membrane cartridge material (no specific model stated), tested 2020-05. MTT assay + morphology on L929 mouse fibroblasts, 24 h co-culture with a 10% serum extract. Result: cytotoxicity grade 2 (mild); 100% extract reduced viability 22.2% vs. control. Conclusion: not cytotoxic under the test conditions.
BenQ Dialysis Technology Test Report No. BDT-NT-231207 — sample MF002 (faucet-mounted purifier), tested 2023-12-20. 700 mL of pure water filtered through the sample; E. coli reduced from 2.2×10³ to <1 CFU/100mL (clearance rate >99.9%).
Taiwan-US Testing Technology (SUPERLAB) Report No. M61-200200105 (page 2 of 5) — sample: hollow-fiber membrane cartridge material, manufactured 2019/12 (no specific model stated), tested 2020-02-13. 9 plasticizers tested (DMP, DEP, DIBP, BBP, DBP, DEHP, DNOP, DINP, DIDP), detection limit 0.05 ppm. Result: none detected.
Taiwan-US Testing Technology (SUPERLAB) Report No. M61-200200105 (page 1 of 5 — the same report as the plasticizer result above) — same sample, tested 2020-02-13. 6 heavy metals tested (arsenic, lead, copper, mercury, cadmium, zinc). Result: none detected.
客製化 Customization
材質選擇Material selection
提供 PES、Nylon、PVDF 與 PP 四種材質。
PES, Nylon, PVDF and PP membranes are available.
客製化封裝Custom packaging
多種尺寸，符合客戶需求。
Multiple sizes to suit customer needs.
新樣式開發New formats
彈性配合客戶開發新樣式產品。
We flexibly develop new product formats with customers.
供應 OEM 產品Supply for OEM products
絲膜供應給過濾模塊與濾筒製造商，納入其最終產品；歡迎洽談您的專案。
Hollow fibers are supplied to filter-module and cartridge manufacturers for their end products; discuss your project with us.
如何取得資料 How to get documents
- 1. 提出需求1. Tell us your need
填寫表單，註明應用、型號或規格。
Send the form with your application, model or specification.
- 2. 我們確認2. We check
由技術與業務確認可提供的文件與樣品。
Our technical and sales team confirms what we can provide.
- 3. 回覆3. We reply
以 Email 回覆；已公開的型錄與檢驗報告可由本頁相關連結查看。如需其他技術規格或文件，請註明產品型號與用途，我們會依可提供的內容回覆。
We reply by email. Published catalogs and test reports can be viewed through the relevant links on this page. For other technical specifications or documents, please state the product model and intended use; we will reply with what we can provide.
